SJT-69.35V6A LiFePO4 charger

Scooty Batteries & Chargers

SJT-69.35V6A LiFePO4 Charger

69.35 V 6 A LiFePO4 Charger, 416 W

Output
69.35 V DC
Current
6 A
Power
416 W
Input
90–264 V AC
Efficiency
Up to 87%

A compact 416 W LiFePO4 charger with wide 90 to 264 V AC input and auto-recovering protections.

  • LiFePO4
  • 416 W
Get a quoteWhatsApp us

Overview

The SJT-69.35V6A LiFePO4 Charger provides reliable, efficient charging for lithium battery systems. It delivers 69.35 V DC at 6 A, about 416 W maximum output. A wide 90 to 264 V AC input and 50 to 60 Hz operation suit varying power conditions. Short-circuit and over-current protection with automatic recovery keep operation safe, while up to 87% efficiency, low ripple and stable output give consistent charging. Its compact 205 × 92 × 46 mm body suits scooters, electric vehicles and other LiFePO4 applications.

  • 69.35 V DC output, 6 A charging current
  • Wide 90 to 264 V AC input
  • Short-circuit and over-current protection with auto recovery
  • Up to 87% efficiency, low ripple
  • Compact 205 × 92 × 46 mm housing

Specifications

ModelSJT-69.35V6A
Product no.YLY-KYP210-11

Nominal input voltage180–240 V AC
Input voltage range90–264 V AC
Input frequency50–60 Hz (range 47–63 Hz)
Maximum input current5 A

Rated output voltage69.35 V DC ± 0.3 V
Charging current6 A
Charge transfer / cut-off current600–1200 mA
Output power416 W

Line regulation±3%
Load regulation±5%
Ripple and noise400 mV p-p
Turn-on delay2 s typical / 3 s max at 115 V AC, max load
Rise time≤40 ms
Hold-up time≥5 ms
Efficiency≥85% @ 100 V AC; ≥87% @ 240 V AC
Overshoot≤15% at power on/off

Short circuitAuto recovery after fault removal
Over-currentAuto recovery after fault removal

Dimensions (L × W × H)205 × 92 × 46 mm

Dielectric strength1500 V AC / 5 mA / 60 s

Operating temperature0 °C to 40 °C, full load
Storage temperature-20 °C to 85 °C
Relative humidity5% to 90% RH
VibrationIEC 721-3-3 3M3 / IEC 721-3-2 2M2
Drop test1 corner, 3 edges, 6 surfaces; 76 cm

Quantity per carton25 pcs

Specifications are subject to change without notice. Images are for reference only.

FAQ

Check your scooty's system voltage (60 V or 72 V class) and the battery bay size (350 × 230 × 175 mm). Send us your model and we will confirm.

Use a charger matched to the battery chemistry and voltage. The 69.35 V charger suits 60 V-class LiFePO4 packs; the 84 V charger suits 72 V-class lithium packs.

The packs are rated IPX7.

Yes. Contact us for dealer and fleet pricing.
