84 V 10 A Lithium Battery Charger
84 V 10 A Lithium Charger, 800 W
- Output
- 84 V DC
- Current
- 10 A
- Power
- 800 W
- Input
- 180–264 V AC
- Certification
- CE
An 800 W metal-cased fast charger for 72 V-class lithium scooty batteries, CE compliant.
- CE
- 800 W
Overview
The 84 V 10 A Lithium Battery Charger is a compact, dependable charging solution for lithium and LiFePO4 battery systems. It delivers a stable 84 V DC output at up to 10 A, about 800 W, for efficient charging. A wide 180 to 264 V AC input supports reliable operation under different power conditions. Built-in short-circuit, over-current and over-voltage protection improves safety, and the compact metal enclosure makes it a practical choice for modern electric scooters.
- 84 V DC output with up to 10 A charging current
- About 800 W output power
- Wide 180 to 264 V AC input
- Short-circuit, over-current and over-voltage protection
- Compact metal enclosure
- CE compliant
Specifications
General
| Model | YLY-841000 |
|---|
Input
| Nominal input voltage | 180–220 V AC |
|---|---|
| Input voltage range | 180–264 V AC |
| Input frequency | 50/60 Hz (range 47–63 Hz) |
| Maximum input current | 4 A |
| Maximum inrush current | 30 A at 240 V AC |
| AC leakage current | 0.25 mA max at 240 V AC |
Output
| Rated output voltage | 84.0 V DC |
|---|---|
| Charging current | 10 A |
| Charge transfer / cut-off current | 500 mA |
| Output power | 800 W |
Performance
| Line regulation | ±3% |
|---|---|
| Load regulation | ±5% |
| Ripple and noise | ≤1000 mV |
| Turn-on delay | ≤2 s at 180 V AC, max load |
| Rise time | ≤40 ms |
| Hold-up time | ≥5 ms |
| Efficiency | ≥76% at 220 V AC; ≥87% at 240 V AC |
| Overshoot | ≤15% at power on/off |
Protection
| Short circuit | Auto recovery after fault removal |
|---|---|
| Over-current | Auto recovery after fault removal |
| Over-voltage | Protects when output exceeds rated voltage |
Physical
| Dimensions (L × W × H) | 245 × 90 × 55 mm |
|---|---|
| Input cable | 3-pin standard plug, 1 mm², 1 m |
| Output cable | DC 2464 16# wire, 1 m, T-type connector |
Safety
| Certification | CE |
|---|
Environment
| Operating temperature | 0 °C to 40 °C, full load |
|---|---|
| Storage temperature | -20 °C to 85 °C |
| Relative humidity | 5% to 90% RH |
| Vibration | IEC 721-3-3 3M3 / IEC 721-3-2 2M2 |
| Drop test | 1 corner, 3 edges, 6 surfaces; 76 cm |
Packing
| Quantity per carton | 15 units, approx. 32 kg, white box + outer carton + strapping |
|---|
| Model | YLY-841000 |
|---|
| Nominal input voltage | 180–220 V AC |
|---|---|
| Input voltage range | 180–264 V AC |
| Input frequency | 50/60 Hz (range 47–63 Hz) |
| Maximum input current | 4 A |
| Maximum inrush current | 30 A at 240 V AC |
| AC leakage current | 0.25 mA max at 240 V AC |
| Rated output voltage | 84.0 V DC |
|---|---|
| Charging current | 10 A |
| Charge transfer / cut-off current | 500 mA |
| Output power | 800 W |
| Line regulation | ±3% |
|---|---|
| Load regulation | ±5% |
| Ripple and noise | ≤1000 mV |
| Turn-on delay | ≤2 s at 180 V AC, max load |
| Rise time | ≤40 ms |
| Hold-up time | ≥5 ms |
| Efficiency | ≥76% at 220 V AC; ≥87% at 240 V AC |
| Overshoot | ≤15% at power on/off |
| Short circuit | Auto recovery after fault removal |
|---|---|
| Over-current | Auto recovery after fault removal |
| Over-voltage | Protects when output exceeds rated voltage |
| Dimensions (L × W × H) | 245 × 90 × 55 mm |
|---|---|
| Input cable | 3-pin standard plug, 1 mm², 1 m |
| Output cable | DC 2464 16# wire, 1 m, T-type connector |
| Certification | CE |
|---|
| Operating temperature | 0 °C to 40 °C, full load |
|---|---|
| Storage temperature | -20 °C to 85 °C |
| Relative humidity | 5% to 90% RH |
| Vibration | IEC 721-3-3 3M3 / IEC 721-3-2 2M2 |
| Drop test | 1 corner, 3 edges, 6 surfaces; 76 cm |
| Quantity per carton | 15 units, approx. 32 kg, white box + outer carton + strapping |
|---|
Specifications are subject to change without notice. Images are for reference only.
FAQ
Check your scooty's system voltage (60 V or 72 V class) and the battery bay size (350 × 230 × 175 mm). Send us your model and we will confirm.
Use a charger matched to the battery chemistry and voltage. The 69.35 V charger suits 60 V-class LiFePO4 packs; the 84 V charger suits 72 V-class lithium packs.
The packs are rated IPX7.
Yes. Contact us for dealer and fleet pricing.
